Mini Flail Mower

Mini Flail Mower

Amenity, Flail Mowers, Mowers
The Mini Flail Mower is designed for compact tractors ranging from 12.5hp to 35hp. This mower provides high-quality cutting and scarifying options, ensuring a long and trouble-free working life through the use of top-quality materials and manufacturing standards.

Overview:

  • Designed for compact tractors with power ranging from 12.5hp to 35hp. With the E models designed for the smallest compacts.
  • Available in cutting widths of 1.0m, 1.1m, 1.2m, 1.4m, and 1.6m to suit different needs.
  • Full-width adjustable rear roller for controlling cutting height and following ground contours.
  • Offers a choice of flails: standard, fine, or scarifying flails to accommodate various applications.
  • Heavy-duty drive line for reliable performance.
  • Simplified maintenance with remote greasing of rotor bearings.
  • Category 1 linkage

Product Images

Main features

  • Cutting Widths:
    The Mini Flail Mower is available in 1.0m, 1.2m, 1.4m, and 1.6m cutting widths, providing options to suit different operational requirements.
  • Adjustable Rear Roller:
    A full-width, adjustable rear roller controls cutting height, follows ground contours, and helps to create an even cut and improved turf surface.
  • Choice of Flails:
    Offers a selection of flails—standard, fine, or scarifying—to meet different mowing and turf maintenance needs.
  • Scarifying Capability:
    Enhances turf health by effectively removing thatch and promoting healthy grass growth.
  • Heavy-Duty Drive Line:
    Constructed for reliable performance and long service life under demanding conditions.
  • Remote Greasing:
    The rotor bearings are equipped with remote greasing, simplifying maintenance and ensuring longevity.


Options:


  • Front Castor Wheels:
    Optional front castor wheels recommended for fine turf work and when using scarifying blades. They provide excellent ground-following characteristics and prevent scalping on undulating ground.
  • Manual Offset:
    Allows for easy adjustment of the mower position to reach around obstacles and along edges.
  • Hydraulic Offset:
    Provides convenient, on-the-fly adjustment of the mower's offset position for greater flexibility and precision.


Applications:


  • Turf Maintenance:
    Ideal for maintaining lawns, sports fields, and other fine turf areas.
  • Scarifying:
    Enhances turf health by removing thatch and promoting new growth.
  • General Mowing:
    Suitable for a variety of mowing tasks in different environments, including residential, commercial, and agricultural settings.

Product Specification

ModelCutting width mm Weight kg No. of flails half Y paired (fitted as standard)No. of paddle flails/ scarifying blades (optional) Minimum tractor hp Front castor kit
M960E960954824 (paddle only) 12.5N/A
M1120E11201005628 (paddle only) 12.5N/A
M10001000150643212.5Optional
M12001200162804012.5Optional
M14001400175884415Optional
M160016001901005018Optional
